TUOSHI 4G Industrial Sim Wifi Router 5dbi Antennas RJ45 Interface
With SMA Port
This device is a high-performance 4G broadband wireless router,
supporting the maximum DL / UL rate of
150 / 50Mbps. Relying on 2 * 2 MIMO technology, it provides
high-quality data communication and optimized WiFi
data transmission. Diversified WiFi standards and encryption modes
ensure the safety and stability of the product.
This SIM Router Equipped with 2 LAN interface, when the 4G router
transmits the WiFi ,you may connect to other
Devices simultaneously, plug the 4G sim card and the router will
transmit the signal into WiFi.And be sure you have
equiped the antenna when you plug the 4g sim card before.
Built in 4x 5dBi high gain antenna with 4 external antennas, speed
up to 300mbps, WiFi signal strongly and wide coverage.
The LTE SIM Router is easy to connect and easy to carry in hand.
Sharing customer to 32 WiFi users, All you need
to do is inserting the SIM card, then you will enjoy the WiFi with
your friends with this portable 4G LTE router.
interface | Network | 2* LAN, |
SIM | 2FF SIM |
Button | Power Reset |
DC Adapter | Input voltage: 12V, 1A |
Base | Routing & wifi chipset model | MT7628N |
Routing & wifi processor info | IEEE 802.11 a/b/g/n |
DDR/SPI | 64MBytes/16MBytes |
RF | Main antenna | External antenna |
Receive diversity antenna | External antenna |
WiFi band | 2400MHz-2483.5MHz |
MIMO for WiFi | 2.4G 5dbi X 2 |
Max. transmitter power for WiFi | 802.11a 14dBm±2dBm; 802.11b 22dBm±2dBm;
802.11g 18dBm±2dBm;
802.11n 16dBm±2dBm; |
Technical Standard | LED Indicator | Supported |
WiFi standard | 802.11b/g/n(2*2 11n features) |
WiFi security | WPA/WPA2 |
OS | Windows XP,Windows Vista,Windows 7,Windows 10,MAC,Linux |
Browser | IE (8.0 and later),Firefox (3.0 and later),Safari (4.0 and
later),Opera (10.0 and later),Chrome (10.0 and later) |
